Westgate DBEL-ACEM-BR-SDT, Westgate Decorative Outdoor LED AC Emergency Unit - Multiple Finishes - White

Westgate DBEL-ACEM-WH-SDT, Westgate Decorative Outdoor LED AC Emergency Unit - Multiple Finishes - White

by Westgate
$296.78
$296.78 - $296.78
$296.78
$255.74
$255.74 - $255.74
$255.74

Technical Specifications

  • Die-cast aluminum housing (Black, Dark Bronze, or White  finish)
  • Sealed and gasketed
  • Photocell control sensor included
  • 4.8V LOng Life, Maintenance-Free, Rechargeable NiCd Battery
  • 90-minute EM-rated with push style test switch and red indicator light.
  • Internal solid-state transfer switch automatically connects the internal battery to LED board for minimum 90-minute emergency illumination
  • Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours
  • Self-diagnostic feature continually tests performance and system to ensure reliable operation and electrical life safety codes.
  • Field-selectable wiring allows for ¡œAC¡ operation of the unit to be controlled using a wall-switch or a photocell or any other switching
  • Wattage: 12W
  • Voltage: 120-277 VAC
  • Operating Temp: 32F to 122F
  • 3-year warranty
  • Suitable for Wet Location

Download PDF File

Catalog Page

Specification

Installation Instructions
